Related Manuals for Gent vigilon

• Security System Gent Nano Operating Instructions Manual
  Panel-based fire detection and alarm system (28 pages)

• Security System GENT Vigilon EN54 Operating Instructions Manual
  4/6-loop control panel / network node fire detection and alarm system (36 pages)

Summary of Contents for Gent vigilon

• Page 1: Installation Instructions

  Installation instructions Vigilon Compact panel based Fire detection and alarm system..

• Page 2: Table Of Contents

  To remove an S-Quad Distributed alarm device load To fi t an S-Quad Lumped alarm device load To fi t a dust cover Vigilon Loop Diagnostic tool To remove a dust cover Typical Vigilon Compact System Vigilon compact parts Vigilon Compact panel..
• Page 3 Vigilon COMPACT fire system Preface Abbreviations This is the third issue of the Installation Alternating current instructions for the Vigilon Compact panel Direct current having 2Km loop card. It covers the End of line approval of 60hz mains frequency, battery charge current data and fi..

• Page 4: Notes

  Installation Notes As fi tted drawings The power-up of the control panel The installer should acquire site specifi c information from the interested parties, and commissioning of the system is for details on the location of products done by the Servicing organisation. for installation.

• Page 5: Earth Continuity

  Vigilon COMPACT fire system Earth continuity Local Manual Call Point All earth connection points should To comply with the requirements of be clean to provide a good electrical EN54-2 : 1997 a conventional manual call conductivity path. To maintain the earth point must be installed near the Control continuity: all earth leads and fi..

• Page 6: En54 Information

  Local Manual Call Point EN54 information Optional functions with requirements of European standard The Control panel complies with the requirements of EN54-2 : 1997. In addition to the basic requirements of the standard the panel conforms to the following optional clauses: Clause Description..

• Page 7: System Wiring

  Vigilon COMPACT fire system System wiring If instructed, the installer may need to terminate as well as connect the cables to the appropriate terminal blocks. Cable separation Where the outgoing and return cables of a loop circuit covers more than the equivalent of one zone they must not run together, for example, either close to the Control Panel or in a service duct.

• Page 8: Cables

  Requirements of cables Cables Mains Supply cable The mains supply cable must be a Requirements of cables standard fi re resisting type and should The British Standard meet PH30 classifi cation, such as BS 5839 Part 1 : 2013 Code of standard or enhanced cable.

• Page 9: Loop Cables

  Vigilon COMPACT fire system Enhanced loop cables Loop cables Approved cables for loop wiring There is a maximum limit (EMC Compliant) of 2Km loop cable usage Draka Firetuf FT120 Enhanced -  allowed per loop circuit. FTPLUS2EH1.5RD This maximum limit is the..

• Page 10: Network Cables

  Network cables Prysmian (formally Pirelli) FP Plus*  1.2Km maximum Panel to Panel or Panel to Network node cable distance The cables marked * utilise 3 Cores each having 1.5mm cross  laminated aluminium tape with a section area tinned drain wire for electrostatic screening.
• Page 11 Vigilon COMPACT fire system Belden TR No. 89729 Prysmian (formally Pirelli)   (Tefl on jacketed) FP200 Flex* 1.2Km maximum Panel to Panel or 800m maximum Panel to Panel or Panel to Network node cable distance Panel to Network node cable distance 2 twisted pairs 3 Cores, each having 1.5mm..

• Page 12: Loop Circuit Design

  Condition of use The Loop Card (COMPACT-LPC-EN) must never be fi tted as a replacement card in a Vigilon Compact panel where 3400 devices are installed on its loop circuits. Up to 2Km loop length is possible with S4 and S3 Mark 2 devices installed on a ..

• Page 13: What Are Lumped And Distributed Alarm Device Loads

  Vigilon Loop Diagnostic tool The Vigilon Loop Diagnostic Tool can be used to diagnose loop circuits driven by Post March 2014 Loop Cards (COMPACT-LPC-EN) fi tted in the panel, this is normally done..

• Page 14: Typical Vigilon Compact System

  Typical Vigilon Compact System Typical Vigilon Compact System The loop allows wiring of addressable devices like fi re sensors, alarm sounders, call points, interface units, mimic and repeat panels, a combined maximum of up to 200 devices are allowed per loop circuit.

• Page 15: Vigilon Compact Panel

  2 loop circuits each up  via batteries for 24 hours plus 0.5 hour to 2Km in length that alarm load can have Vigilon analogue addressable LCD with back light to display event devices, like fi re sensors, manual call  information points, interface units and repeat panels.

• Page 16: Technical Data

  Technical data Technical data Control panel Standard Designed to EN54-2:1997 + A1:2006 (and include optional clauses 7.8, 7.9, 7.9.1, 7.10, 7.10.1, 7.11, 7.12.3, 8.3, 9.5 and 10) Approval LPCB approved Panel dimensions in mm height 403 x width 338 x depth 101 Panel weight 8.6Kg approximately without batteries 1 - 12V 12Ah battery - 4Kg (2 batteries are required)
• Page 17 Vigilon COMPACT fire system Ports Port 0 and fuse RS485 -Repeat indicator panel (PB15) (Mode: Repeat) Includes a 24V supply protected by FS3 Fuse 200mA TE5 on MCB Port 1 and 2 RS232 -Printer (PB6) (Mode: Std, Printer, Universal or Ascom)

• Page 18: Power Supply

  Technical data Power supply Always use the recommended replacement batteries, as there is a risk of an explosion if incorrect battery is used. Dispose of used batteries according to the manufacturer’s instructions. Standard Designed to EN54-4:1997 + A1:2002 and A2:2006 Mains supply voltage and 230V -15% +10% 50Hz/60Hz fuses..

• Page 19: Panel Installation

  Vigilon COMPACT fire system Panel installation Parts in the Spares pack The Vigilon Compact Panel is supplied in Fuse T3.15AL250V parts, it is important to check the contents 20mm x 5mm of each package: Back box assembly Fuse T3.15A (TE5) ..

• Page 20: Mounting & Cable Entry Points

  Mounting & cable entry points Mounting & cable entry points Any unused knockouts that have been removed should not be left open. All other cable entry RS485 RS232s Mon I/P Clean Cont. Mains 7 Earth points cable Network Aux. Relays Loops Master alarms entry Cable..

• Page 21: How To Semi-fl Ush Mount The Control Panel

  Vigilon COMPACT fire system How to semi-fl ush mount the control panel The control panel may be semi-fl ush mounted using a fl ush surround (COMPACT-FLUSH). A stainless steel fl ush surround is available as an option (COMPACT-FLUSH-SS) and if fi tted it requires a stainless steel door (VIG-RPT-DOOR-SS).

• Page 22: Fitting The Inner Door

  Fitting the inner door Fitting the inner door Inner door REMOVAL OF COVER EXPOSES HIGH VOLTAGE Back box Ribbon cable and clamp Back box Inner door REMOVE ONLY DURING COMMISSIONING CAUTION Ensure correct fuses are fitted Earth lead from Ferrite Core back box - inner door Cable and clamp are fitted during..

• Page 23: Cable Termination On Enclosure

  Vigilon COMPACT fire system Cable termination on enclosure The wire length between MICC the cable termination and Softskin (Fire Tuf) CABLE TERMINATION CABLE TERMINATION point of connection must MICC CABLE MICC CABLE EARTH be as short as possible. DRAIN Softskin Cable..

• Page 24: Mains Supply

  Mains supply Mains supply Ensure that the mains supply cable enters the panel through a dedicated cable entry, located adjacent to the mains terminal block and also ensure it is segregated from the loop wiring. These fi re alarm system products are not designed to be powered from IT Power systems.

• Page 25: Removable Terminal Block

  Vigilon COMPACT fire system Removable terminal block To ease installation the terminal blocks on the Master Control Board can be unplugged from the board. removable Terminals for external circuits on Master Control Board The Master Control Board (MCB) holds all the terminals for the connection of fi re alarm loop circuits, master alarms, auxiliary relays, clean contacts, repeat indicator panel and monitored input.

• Page 26: Device Loop Circuits

  Device loop circuits Device loop circuits The two device loop circuits can each accept connection of addressable devices / outstations, up to 200 maximum per circuit. To maintain earth continuity on a loop, the loop cable screen must be continued through each system device, whether the earth is connected to a device or not.

• Page 27: Master Alarm Circuits

  Vigilon COMPACT fire system Master alarm circuits The two master alarm circuits accept the connection of conventional alarm sounders, such as the conventional S-Cubed products. 10K Ohms - End-of-line resistor fitted in the last alarm sounder Conventional alarm sounders MA1+ MA1- MA2+ MA2-..

• Page 28: Auxiliary Relay Circuits

  Auxiliary relay circuits Auxiliary relay circuits The control panel operates the auxiliary contacts when the confi gured event is received from the system. The auxiliary relays 1 and 2 contacts can be used to control external equipment, such as an automatic dialer that makes the call for fi re fi ghting action. The relays can be individually re-confi..

• Page 29: Monitored Input Circuit

  Vigilon COMPACT fire system Monitored input circuit This may be used for class change application in schools. The monitored input at the fi re panel is activated by an external switch installed a maximum of up to 100m cable distance away from the panel.

• Page 30: Usb Port

  USB Port USB Port The Port 3 is a USB port that is used to connect to the commissioning tool. This tool allows ease of confi guring the system. PORT 3 is the USB port that MASTER CONTROL can be accessed BOARD through connector P16 of the Master Control Board..

• Page 31: Repeat Indicator Panel

  Vigilon COMPACT fire system Repeat indicator panel Up to four repeat indicator panels can be connected directly to the fi re panel at Port 0. The furthest repeat indicator panel can be installed a maximum of 1Km cable distance away from the fi re panel.

• Page 32: Network Wiring

  Network cable screen continuity Network wiring In countries where the European EMC directive is in force use only those cables that are EMC Compliant, see list under the heading Network cables. Network cable screen continuity Ensure a good screen continuity joint exist where there is a split cable. DO NOT mix cables of different types on the same leg of a network as this will create impedance imbalance and disruption to data communication.

• Page 33: Network Card Connections

  Vigilon COMPACT fire system Network card connections The Network card has the terminals for network cable connection. The Network card is fi tted during system commissioning. Master Control Board PB1A PB1B Terminals for network connections Network Card Loop Card Loop Card..

• Page 34: Network Wiring

  Network wiring Network wiring N/C = No connection Cable screen PB1B PB1B PB1B PB1A PB1A PB1A Connections for Network card in Connections for Network card in Card 2 Card 2 MASTER CONTROL BOARD MASTER CONTROL BOARD Control Panel Control Panel Control Panel Cable screen PB1B..

• Page 35: On Completion Of Panel Installation

  Vigilon COMPACT fire system On completion of panel installation On completion of cable installation ensure the earth lead between the backbox and inner door is fi tted. Also the inner and outer doors are closed. a. Close the inner door using a screw driver.

• Page 36: S-quad Sensors

  On completion of panel installation S-Quad Sensors This following is short information on the S-Quad product range. The S-Quad product integrates dual angle smoke, heat and carbon monoxide gas detection with electronic sounder, speech and visual alarm in one assembly. Full information on S-Quad Devices can be downloaded from www.gentexpert.co.uk by registered users.

• Page 37: Siting

  Vigilon COMPACT fire system Siting A S-Quad device plugs into a dedicated Base that is installed in the protected premises. The Bases should be sited in locations as defi ned by the project plans and by BS 5839 : Part 1 : 2013.

• Page 38: Metal Back Box

  Metal back box Metal back box A metal back box must be used for surface or semi-fl ush mounting. The earth continuity must be maintained throughout the whole loop. The earth must be securely connected to the back box. Standard Metal Box Cable gland Loop cable Loop cable..

• Page 39: Programmable Input/output

  Vigilon COMPACT fire system Programmable input/output All S-Quad devices can be confi gured as either monitored input or unmonitored output. The factory setting of the programmable input / output is set as an unmonitored output, to drive an external repeat LED without a series resistor. There is a maximum cable length limit of 15 metres from the S-Quad base to the external I/O Unit.

• Page 40: Tools For S-quad

  Tools for S-Quad To fi t a dust cover Tools for S-Quad Place the dust cover onto the tool inside An extractor tool allows removal and the cradle. Offer the cover to the S-Quad, fi tting of the S-Quad device head into the locate and push to fi..

• Page 41: Vigilon Compact Parts

  Vigilon COMPACT fire system Vigilon compact parts This section lists parts associated with the Vigilon compact panel. For further information on the availability of the parts contact your supplier. Control Panels COMPACT-24-N Vigilon Compact control panel (networkable) c/w 1 - Loop card..
• Page 42 S-Quad - Sensors Notes..
• Page 43 Vigilon COMPACT fire system Notes..
• Page 44 Do not burn. accordance with national or local legislation. Gent by Honeywell reserves the right to revise this publication from time to time and make changes to the content hereof with- out obligation to notify any person of such revisions of changes.
